CHAUVET GIGBAR BRIDGE ILS 2-in-1 Moving Heads and Wash Lighting System with Case

CHAUVET
SKU:
181958
|
UPC:
781462226558
$999.99
(No reviews yet)
Shipping:
Free Shipping
Current Stock:
Adding to cart… The item has been added

 GIGBAR BRIDGE ILS  CHAUVET

 2-in-1 Moving Heads and Wash Lighting System



The Chauvet DJ GigBAR Bridge ILS combines powerful moving heads and washes into a single, compact unit for a complete lighting experience. Designed with ILS compatibility, this system integrates effortlessly with other ILS-enabled fixtures to create stunning, synchronized light shows. The moving heads feature 9 colors, 9 gobos, and creative programming options with separate color and gobo wheels. The wash lights utilize hex-color RGBAW + UV LEDs for vibrant, customizable lighting effects. Equipped with a built-in D-Fi transceiver, the GigBAR Bridge ILS supports wireless DMX and ILS signals, eliminating the need for extensive cabling. Its totem mode ensures the moving heads remain focused on the dance floor, making it ideal for weddings, parties, and live performances. With quick setup, secure connections, and a carry bag for easy transport, the GigBAR Bridge ILS offers maximum flexibility and portability for any event.



Included:

  • GigBAR Bridge ILS

  • Power Cord

  • 2 Hanging Brackets

  • Carry Bag

  • Quick Reference Guide

Features:

  • 2-in-1 system with pre-mounted moving heads and wash lights for rapid setup.

  • Powerful moving heads with 40W cool white LED and separate color/gobo wheels.

  • Wash lights feature 4 hex-color RGBAW + UV LEDs for dynamic color mixing.

  • Built-in D-Fi transceiver for wireless DMX and ILS communication.

  • Totem Mode for focused moving head effects on the dance floor.

  • Full-color LCD display for easy access to settings and functions.

  • Locking system for quick and secure fixture connections.

  • Power linking supports multiple units for simplified setups.

Specifications:

  • DMX Channels: 3, 16, or 46.

  • Light Source (Moving Head): 1 x 40W cool white LED; 50,000-hour life expectancy.

  • Light Source (Wash): 4 x 10W RGBAW + UV LEDs; 50,000-hour life expectancy.

  • Beam Angle (Wash): 22°; Field Angle (Wash): 38°.

  • Maximum SPL: 191 W, 1.5 A @ 120V; 175 W, 1 A @ 230V.

  • Illuminance (Moving Head): 6,594 Lux @ 2m; (Wash): 375 Lux @ 2m.

  • Power Linking: 8 units @ 120V; 13 units @ 230V.

  • Connectivity: 3-pin XLR DMX, D-Fi wireless, and PowerCON input.

  • Dimensions: 26" x 2.8" x 12" (660 x 71 x 305 mm).

  • Weight: 18.6 lbs (8.4 kg).

  • Approvals: CE, RoHS, FCC.
