DYNACORD L1300FD Rackmount 2x650w DSP Rackmount Power Amplifier

 L1300FD-US  DYNACORD

 2x650w DSP Live Performance Power Amplifier

The Dynacord L1300FD is a 2 x 650W DSP Power Amplifier. Dynacord L Series are professional dual channel audio amplifiers for live and mobile applications. Integrated digital signal processing provides access to professional speaker processing with FIR Drive technology. L Series amplifiers utilize Class A/B resp. Class H topologies, which provide market leading acoustic performance and reliability. The connectivity is optimized for the needs of mobile applications. A front panel LC display allows local control and supervision of the amplifier. An intuitive system control software allows fast system setup, flexible system control and comprehensive supervision.

Features:

• Live performance DSP amplifier

• Fully integrated professional speaker processing with FIR Drive technology

• Market leading acoustic performance and rock-solid reliability

• True 2-ohm stability

• Intuitive system control software, makes setup and control easy

Specifications:

• Load Impedance: 2Ω / 2.6Ω / 4Ω / 8Ω

• Maximum Output Power, Single Channel: 2Ω=1100W; 2.6Ω=950W; 4Ω=660W; 8Ω=350W

• Maximum Output Power, Dual Channel: 2Ω=1000W; 2.6Ω=850W; 4Ω=600W; 8Ω=320W

• Maximum Output Power, Bridged: 4Ω=2000W; 8Ω=1200W

• Maximum RMS Voltage Swing, THD = 1%, 1kHz: 55.3 V

• Voltage Gain ref.1 kHz: 32.0 dB

• IMD-SMPTE, 60 Hz, 7 kHz: < 0.1%

• DIM 30: < 0.05% (3.15 kHz, 15 kHz)

• Maximum Input Level: +21 dBu

• Crosstalk: < -80dB (ref. 1 kHz, at 100 W/4Ω)

• Frequency Response: 10 Hz to 21 kHz (±1 dB)

• Input Impedance, active balanced: 20kΩ

• Signal-to-Noise Ratio (A-weighted): > 104 dB

• Output Noise, A-weighted: < -68 dBu

• Output Stage Topology: Class AB

• Power Requirement: 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)

• Power Consumption: 550 W (Maximum Output Power @4Ω)

• Protection: Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, In rush current limiters, Turn on delay

• Cooling: Front-to-rear, 3-stage-fans

• Safety Class: I

• Available Color: Black

• Dimensions (H x W x D): 3.46" x 19.02" x 18.2" (88 x 483 x 462.4mm)

• Weight Net: 28.44 lbs. (12.9 kg)

• Signal Processing: FIR Filters, Audio Limiters; Output delay per channel; 31 band GEQ per channel; PEQ per channel; Load impedance

• Mains Fuse: 240 V/230 V: T10AH; 120 V/100 V: T20AH

• Operating Temperature Range: 40°F to +105°F (+5°C to +40°C)

• Total Harmonic Distortion: < 0.05% (at 450 W/4Ω MBW = 80 kHz, 1 kHz)

SALE: $889.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
