YORKVILLE SA153 Synergy Series 5000w Peak Active 15" Co-Axial Full-Range Speaker Cabinet

YORKVILLE
SKU:
179875
|
UPC:
840402043867
$3,715.00
(No reviews yet)
Shipping:
Free Shipping
Current Stock:
Adding to cart… The item has been added

 SA153  YORKVILLE

 5000w Peak Active 15" Co-axial Speaker

The Synergy Array Series is a truly revolutionary active point source system with unmatched flexibility, power, and directivity control. The Synergy System offers users unrivaled simplicity without sacrificing sonic performance.

The Synergy Array Series consists of the SA153 full-range powered cabinet, along with the SA315S powered subwoofer. This dynamic duo makes the ultimate point source speaker system scale-able for club gigs of all sizes, outdoor festivals, inclined seating venues, and arenas. Never before has a large point source system with this much output and sound quality been this easy to set up and use.


Features:

  • 3-way 15" full-range powered Co-axial speaker

  • Incorporates Tom Danley's patented Paraline Lens and Synergy Horn technologies

  • Exceptionally high output and pristine clarity

  • Simple and secure rigging hardware

  • Extremely well controlled coverage pattern

  • Made in Canada

Specifications:

  • Active or Passive: Active

  • Program Power (Watts): 2600 Watts Program (5000 Watts Peak)

  • Biampable: Triamp

  • Measured Max SPL (C-Weighted, Max Hold): 131 dB Cont. 137 dB Peak

  • Frequency Response (Hz +/- 3dB): 55Hz-18k

  • Dispersion (°H x °V): 22.5x45 Asymetrical 10 Up, 35 Down

  • Crossover Frequency (Hz): 400Hz, 7kHz

  • Cabinet Configuration: Patented Synergy Horn and Paraline Lens Technology

  • Driver Configuration: 1x15" LF woofer, 1x MF/HF Co-ax Compression

  • HF Driver(s): 1.75" Diaphragm/Voice Coil Annular Co-axial

  • HF Program Power (Watts): 300 Watts

  • HF Impedance (Ohms): 16-ohm Load

  • HF Protection: Peak and Average Limiting

  • MF Driver(s): 3.5" Diaphragm/Voice Coil Annular Co-axial

  • MF Program Power (Watts): 300 Watts

  • MF Impedance (Ohms): 16-ohm Load

  • MF Protection: Peak and Average Limiting

  • LF Driver(s): 1x15" Neo Woofer with 3.5" Voice Coil

  • LF Program Power (Watts): 2000 watts Program (4000 watts Peak)

  • LF Impedance (Ohms): 8-ohm Load

  • LF Protection: Excursion, RMS

  • HF Power Amplifier (Watts): 300W

  • HF Amplifier Type: 3-Tier Class H

  • MF Power Amplifier (Watts): 300W

  • MF Amplifier Type: 3-Tier Class H

  • LF Power Amplifier (Watts): 2000W

  • LF Amplifier Type: Class D

  • Cooling Scheme: Convection

  • Power Cable: Removable Locking Powercon True Input and Loop Thru Output

  • Power Switch: Yes

  • Power Consumption (typ/max): 220 VA / 400 VA

  • Inputs: 1 XLR, 2 x XLR Loop

  • Input Sensitivity (Vrms Sine): Line in 1.4 at center, 0.56 at max

  • Level Controls: Volume

  • EQ Controls: HF/MF Boost select, Fullrange/Sub switch

  • LED Indicators: Power, Limit, Clip

  • Enclosure Materials: Multiply 15mm Birch Plywood

  • Standard Rigging Hardware: RAIL and LOCKBAR Rigging System (Top and Bottom)

  • Stacking Feature: Interlocking UHMW Feet (Top and Bottom)

  • Covering / Finish: Paint

  • Dimensions (DWH xbackW, inches): 24 x 21 x 26.5 x 12.25

  • Dimensions (DWH xbackW, cm): 60.9 x 53.3 x 67.3 x 31.1

  • Weight (lbs/kg): 115/52.1
