PIVOT CUE 512 Professional DMX Lighting Console with Joystick, 7" Touch Screen & Touch Faders


PIVOT CUE 512 Professional DMX Lighting Console with Joystick, 7" Touch Screen & Touch Faders

Free Shipping

Product Description

 CUE 512  PIVOT


 Professional DMX Lighting Console


The progressive PIVOT CUE 512 can be the control center of your event. Using its large 7” color touch screen allows for easy and intuitive graphical control of all your DMX products and quick programming. It even includes an extensive fixture library that can be edited. If you need an additional universe of DMX, just add a PIVOT WING and you gain more fader handles, playback buttons and another 512 channels.

Technical Specifications Pivot Cue 512 DMX Console:



  • Color Display touch-screen TFT LCD 7"

  • 6 control keys for editor

  • 6 configurable sliders as playback, master group

  • 6 configurable keys as play, flash, DBO

  • 12 keys for direct access to playback and CUES

  • 4 touch-fader for the control of the attributes during the programming and control of the effects and during playback and manual use

  • Joystick for PAN and TILT movement control with lock and fine/super fine keys


  • Effective graphic interface able to easily manage programming and playback for a maximum of 144 cue list organize in 12 pages each having a maximum of 999 cues

  • 512 channels for each single universe DMX for the control of dimmer and/or intelligent projector, available simultaneously on XLR connector 3-Pin

  • Up 3 universes of DMX with Pivot Wing 512 DMX Expansion (CT-PIVOTW512 sold separately)

  • Up to 36 Cue-list run concurrently (with 2 Expand connected)

  • “Shape engine” customizable and applicable to different functions (PAN&TILT - DIM - COLOR - GOBO - BLADE)

  • Up to 6 different families of "palettes" programmable for a flexible and easy control of intelligent projectors

  • Up to 999 Cues for each playback

  • Library "personalities" upgradeable, creating fixture via software for PC (included)

  • "Palettes" Gam/Lee and Rosco preprogram usable on all machines with mixing colors RGB or CMY

  • Maximum Number of storable cues to show: 999

  • RDM ready

  • Wireless ready (wireless transmitter sold separately)

  • Power Input: 100-240V 50-60Hz

  • USB drive (included)

  • USB Gooseneck LED light (included)


  • DMX out: 1x XLR 3-Pin

  • Expand: 2x RJ45 for expansions connection

  • USB 1x port for backup, lamp power supply and update the fixture

  • Jack 6.3 mm for connecting the pedals for controlling the gearbox scenes

Size and Weight

  • Size: 16.5" x 3.9" x 11.34"

  • Weight: 3.4 kgs/7.5 lbs

SALE: $2299.99


FREE S&H in continental US (e-mail for international / offshore USA rates)
