PRESONUS STUDIOLIVE 32SX Compact Digital Motorized Fader Audio Console Mixer

PRESONUS
SKU:
180740
|
UPC:
673454008146
$2,999.99
(No reviews yet)
Shipping:
Free Shipping
Current Stock:
Adding to cart… The item has been added

 STUDIOLIVE 32SX  PRESONUS

 Compact Digital Motorized Fader Audio Console Mixer

Efficient. Powerful. StudioLive 32SX from PreSonus is a studio grade, flexible routing, and compact 32-channel digital mixer capable of powering 40 mixing channels, 26 mix buses, and 286 simultaneous processors. Powered by a dual-core PreSonus FLEX DSP Engine in a sleek profile, this mixer is loaded with processing power and ideal for environments where desk real estate is at a premium. Manage 32 input channels in two fader layers with split-fader workflow, while having access to mix outputs on eight additional faders. StudioLive 32SX features 32 XMAX mic preamps, 22 mix outputs, four stereo reverberation systems, as well as Fat Channel plug-in models on every input channel and mix bus.

Allowing you to create a custom, scalable AVB network system, StudioLive Series III digital mixers let you patch any analog input or digital return (AVB, USB, or SD Card) to any channel to customize your mix configuration—without unplugging a cable. Redundant recording options and an automated Virtual Soundcheck mode are provided from 128 (64x64) channels of recording over USB and an integrated 34-track SD recorder. A 7" Touch Display gives you instant access to the dynamics processing parameter, as well as ten included vintage EQs, classic compressor Fat Channel plug-in models, and 15 additional models. Combined with other products within the StudioLive Series III (sold separately), you can create the custom, scalable ecosystem for your desired complete networked solution.


Applications:

  • Installed Sound

  • Live Touring

  • Mobile Applications

  • House of Worship

  • Theatre

  • Broadcast

  • Corporate

Features:

  • Powered by the new dual-core PreSonus FLEX DSP Engine to provide the most processing of any digital mixer in its class

  • 40 input-channel digital mixer with 25 touch-sensitive motorized faders

  • 26 mix buses including 16 individually configurable FlexMixes (aux, matrix, or subgroup options)

  • 286 simultaneous processors with State Space-Modeled Fat Channel compressor and EQ plug-ins available on every input channel and output bus

  • FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses

Specifications:

  • ADC Dynamic Range: 115 dB (A-wtd, 48 kHz)

  • DAC Dynamic Range: 115 dB (A-wtd, 48 kHz)

  • USB Recording Port: USB 2.0, Type-B

  • Bluetooth™ Input: 4.1, stereo

  • AES/EBU Output: XLR Male

  • Network Control Port: RJ-45

  • AVB Audio Network Port: Locking XLR Ethernet

  • Internal Processing: 32-bit, floating point

  • DSP Engine: Quad-core FLEX DSP

  • Sampling Rate: 44.1 and 48 kHz

  • A/D/A Bit Depth: 24

  • Reference Level for 0dBFS: +18dBu

  • Total System Latency: 1.9ms (local routing, analog in-analog out, all processing active)

  • Power Connector: IEC

  • Input-Voltage Range: 90 to 230VAC (±10%)

  • Power Requirements (continuous): 85 W

  • Recommended Ambient Operating Temperature: 32 ° - 104 ° Fahrenheit

  • Dimensions: 25.98" x 22.97" x 6.51"

  • Weight: 30 lbs

SALE: $3999.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
