SHURE ANIUSB-MATRIX Dante Audio Network Interface with USB Output

 ANIUSB-MATRIX  SHURE

 Dante Audio Network Interface

The Shure ANIUSB-MATRIX USB Audio Network Interface complements the existing ANI4IN, ANI4OUT, and ANI22 products. It offers the ideal performance, connectivity, and affordability for audio/video conferencing installations in small and medium-size meeting rooms when a premium microphone solution is desired, and acoustic echo cancellation of an A / V conferencing codec will be used.

The ANIUSB-MATRIX connects 4 Microflex® Advance™ or Microflex® Wireless microphone channels via Dante (4 in / 2 out), and provides analog connectivity (1 block in / 1 block out) to a room audio / video conferencing system or a PC-based A / V conferencing application via USB (1 in / out).

An internal matrix mixer offers flexible routing, allowing users to route any input to any output. A 4-band parametric EQ filter is also available on the analog and USB outputs.

Features:

• Connects 4 Dante audio inputs and 1 analog input to an A / V conferencing system or a PC-based videoconferencing application

• Flexible signal routing and connectivity: analog audio (1 block in / 1 block out) to room A / V conferencing system; USB (1 in / out) to connect to laptop or room PC

• Power-over-Ethernet (PoE) eliminates the need for an outboard power supply

• Compact form factor is easy to mount without equipment rack

Specifications:

• Polarity: Non-inverting, any input to any output

• Power Requirements: Power over Ethernet (PoE), Class 0. (PoE Plus compatible)

• Power Consumption: 6.5W, maximum

• Weight: 1.5 lbs (668 g)

• Dimensions (HxWxD): 1.6" x 5.5" x 5.0" (4 x 14 x 12.8 cm)

• Control Application: HTML5 Browser-based

• Operating Temperature Range: 20°F - 104°F (-6.7°C - 40°C)

• Storage Temperature Range: -20°F - 165°F (74°C - -29°C)

USB Connections

• (1) USB 2.0, Type B

• Single port carries 1 input and 1 output channel (Summed mono)

Network Connections (Dante Digital Audio)

• (1) RJ45

• (4) input channels, 2 output channels

SALE: $730.00

FREE S&H in continental US (e-mail for international / offshore USA rates)
