TECHNI-LUX MSCULPT20/QW 20w COB LED RGBW Profile Spotlight

 MSCULPT20/QW  TECHNI-LUX

 20w COB LED RGBW Profile Spotlight

The mSculpt LED series is engineered to provide value and efficiency in a mini compact body. The mSculpt 20 LED profile provides a replacement for 50-75w halogen units but with the added feature of color mixing capabilities. Using RGBW control, millions of colors may be produced. Designed as an extremely versatile and lightweight piece of lighting equipment featuring a gobo holder and shaping profile blades. Smooth DMX dimming and color mixing makes it ideal for shows, retail and convention applications. Four lens options are available.

Includes:

• 14-36 Degree Lens

• Color frame

• Gobo holder

• XLR jumper cable

• PSU

Spotlight Specifications:

• Light Source: 20w COB RGBW (red, green, blue, white) LED

• Low voltage power input

• Master or Standalone operation

• Beam Angle: 14-degree, 19-degree, 26-degree, and 36-degree (Option)

• Dimming: 0-100% Linear

• Barrell rotation: +/- 45 degrees

• Shaping blades/shutters: 4

• Gobo size: E standard

• Data Connection: DMX in/out via 5pin XLR

• Data Control: DMX 512

• DMX Channels: 8

• Settings: 4-digit display with 3 button menu

• Cooling: Heat sink

• Adjustable mounting yoke with 3/8" hole

• Current Draw: 2.0 amps

• Certifications: CE, UL power supply

• Power Input: 12vDC, with PSU 100-240vAC 50/60hz

• Power Consumption: 22W

• Size: 6.25"L x 4.5"W x 6.5"H without lens, yoke up

• Weight: 1.02 kgs / 2.25 lbs without lens

• Color: Black

• Material: Aluminum and Plastic

Lens Specifications:

• Standard resolution

• Glass lens

• Lightweight plastic housing tube design for LED fixtures only

• Dual Filter Frame holding slots 2-3/4 x 2-3/4 inch

• Locking frame spring clip

• Size: 4" x 3" x 3"

• Weight: 0.13 kgs/ 0.28 lbs

• Color: Black

SALE: $449.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
